Close-coupled Pumps With Magnetic Coupling

Description

Close-coupled Pumps With Magnetic Coupling Advantages

  • Universally deployable pumps which are suitable for many applications
  • High-quality, robust and reliable pumps for continuous operation
  • Low-maintenance and safe in operation
  • Small dimensions
  • High motor efficiency

Close-coupled Pumps With Magnetic Coupling Description

  • High-quality magnetic couplings
  • Threaded and SAE flanges
  • Spheroidal graphite cast iron or stainless steel designs
  • PM synchronous motor (VSD)
  • Operation with frequency converter only
  • Tmax
    Water up to 160 °C
    Oil -100 °C up to +300 °C, higher temperatures on request

MU…-MK-PM

Close-coupled, with controlled PM synchronous motor

ISO

Water max. 160 °C

Oil -100 °C – +300 °C

1000 – 4000 1/min

max. 98 m / 23 m³/h

US

Water max. 160 °C

Oil -100 °C – +300°C

1000 – 4000 1/min

max. 320 ft / 110 GPM
